Model RB320
Processing veneer All kind of veneer
Min.length of veneer Around 280mm
Knife shape wave
Width of veneer 50-250mm
Jointing part width 23mm.
Max.processing width 320mm
Thickness of the veneer 0.25-0.5mm
Jointing times in minute 5-8 times
Heating temperature 120-240℃ (248-392℉)
Heating pressure 5026N (0.5Mpa)
Input power 2.2KW
Input votage 380 V/50Hz
Out size 1800mm(L)*1300mm(W)*1805mm(H) Finger-jointer
1000mm(L)*720mm(W)*1300mm(H) Rewinder
Require working space 8000mm*2000mm only for reference
Gross weight Approx. 780kg
Packing size 2000mm(L)*1800mm(W)*1800mm(H)
Q: Are you an equipment manufacturer?
A: Yes, RANOW was founded in 2009 and specializes in wood processing machinery manufacturing.
Q: Where is your factory located?
A: Our factory is located in ZhangJiang China
Q: What kind of equipment can you produce?
A: Veneer jointing machines, veneer rewinding machines, etc.
Q: What are your payment terms?
A: 30% advance payment, and the balance should be paid before shipment.
Q: How long does it take to complete the equipment?
A: Most orders will be completed within 45 days, depending on the equipment model.
