Glue spreader parameter
|
Model Processing veneer Max.width of processing Backing speed Glue spreader shaft diameter |
|
FL450 All kind of veneer 350mm 10m-35m/min 140mm |
|
|
Releaser shaft |
75mm/200mm |
|
|
|
Input power |
1.5 KW |
|
|
|
Input votage Out size Require working space Total weight
|
380 V 50Hz 2260mm(L)*1000mm(W)*1140mm(H) (2.57M3) 3000mm*2000mm only for reference Approx. 400kg |
|
|
Pressor parameter
|
Model Processing veneer Max.width of processing Backing speed Backing shaft diameter Heating shaft diameter Heating temperature Input power Input votage Out size Require working space Total weight |
FL450 All kind of veneer 350mm 10m-35m/min 140mm. 140mm 100-200℃(212-392℉) 4.5KW 380 V 3phase 1280mm(L)*900mm(W)*1900mm(H) (2.19M3) 1600mm*2000mm only for reference Approx. 450kg |
Tunnel Dryer
|
Model Processing veneer Max.width of processing Heating power Heating technique Blowing motor Heating temperature Input votage Out size Require working space Total weight |
FL450 All kind of veneer 400mm 6KW Blowing 0.15KW 100-200℃(212-392℉) 380 V 3phase 1250mm(L)*580mm(W)*1950mm(H) *3(4.24M3) 4000mm*2000mm only for reference Approx.150kg (each) |
Rewinder station
|
Model Processing veneer Max.width of rewinding Input votage Motor power Gear Out size Require working space Total weight |
FL450 All kind of veneer 350mm 380 V 3phase 0.75 KW 1:20 1170mm(L)*1000mm(W)*1120mm(H) (1.31M3) 1500mm*2000mm only for reference Approx.120kg |
Q: Are you an equipment manufacturer?
A: Yes, RANOW was founded in 2009 and specializes in wood processing machinery manufacturing.
Q: Where is your factory located?
A: Our factory is located in ZheJiang china
Q: What kind of equipment can you produce?
A: Veneer jointing machines, veneer fleecing machines, etc.
Q: What are your payment terms?
A: 30% advance payment, and the balance should be paid before shipment.
Q: How long does it take to complete the equipment?
A: Most orders will be completed within 40 days, depending on the equipment model.
